| একক দাম: | 500~3000 USD |
|---|---|
| ন্যূনতম। ক্রম: | 1 Piece/Pieces |
মডেল নাম্বার.: GM
Standard: Din, Astm, Gost, Gb, Jis, Ansi
Technics: Forging
Feature: Recycle
Material: Iron
Materials: 38crmoala, 40cr, SKD61, 31crmov9, D2, Gr12MOV
Hardness Of Tempering: Hb280-320
Nitriding Hardness: Hv850-1000
Nitriding Layer Depth: 0.45~0.7mm
Nitriding Brittleness: Grade II
Surface Roughness: ≤ Ra0.4
Screw Straightness: 0.015mm
Chrome Coating Thickness: 0.025~0.10mm
Dual Alloy Hardness: HRC50-65
Double Alloy Depth: 0.8~2.0mm
MOQ.: 1 Set
ডেলিভারি সময়: 30-60 Days
Transport Package: Wooden Case
Specification: Screw Diameter 20~650MM
Trademark: GUANG YOU SCREW
Origin: Zhejiang, China
এইচএস কোড: 847790
উৎপাদন ক্ষমতা: 18000sets/Year
কাস্টমাইজেশন: উপলব্ধ
After-sales Service: We Can Offer Measurement and Mounting Service
Warranty: 6-12 Months Under Normal Use
শিপিং খরচ: Contact the supplier about freight and estimated delivery time.
যোগানের ক্ষমতা: 18000sets/Year
Guangyou পরিধান এবং জারা প্রতিরোধী স্ক্রু এবং ব্যারেল সঙ্গে উত্পাদনশীলতা বৃদ্ধি
|
Why choose Guangyou?
• Professional Expertise: More than 30 years in screw & barrel design and manufacturing.
• Advanced Equipment: CNC machining centers, vacuum nitriding furnaces, and precision grinding machines ensure accuracy and consistency. • Material Excellence: Imported alloy steel and bimetallic solutions for long-lasting durability. • Customized Solutions: We design screws & barrels according to customer's machine model, raw materials, and production requirements. • Strict Quality Control: 100% inspection of hardness, concentricity, and dimensional tolerance before delivery. • Global Service: Our products are widely exported to Europe, South America, Southeast Asia, and Africa, earning long-term trust from international clients. FOQ
1. How about MOQ:
1pcs is available. 2. What is the lead time? Lead time varies based on size and bimetallic status. 40-50 days for nitriding single screw and barrel (Φ20-Φ90) 50-60 days for nitriding single screw and barrel (Φ90-Φ180) 60-70 days for nitriding single screw and barrel (Φ180-Φ250). Over 70 days for nitriding single screw and barrel (Φ250-Φ500). 45-50 days for nitriding parallel twin screw and barrel (Φ45-Φ90). 50-60 days for nitriding parallel twin screw and barrel (Φ90-Φ135). Over 60 days for nitriding parallel twin screw and barrel (Φ135-Φ350). 35-45 days for nitriding conical twin screw and barrel (Φ25/50-Φ80/156). 50-60 days for nitriding conical twin screw and barrel (Φ92/188-Φ110/220). Over 60 days for nitriding conical twin screw and barrel (Φ115/230-Φ185/340). Bimetallic screw and barrel require an additional 5 days. 3. What is the lifespan of the screw and barrel? Lifespan varies with formula and heat treatment. For 30phr nitriding, expect 3-5 years. Bimetallic screw and barrel have an extended lifespan. 4. How to submit an inquiry? Feel free to contact via email or WhatsApp. Visiting our factory is recommended. 5. How can we ensure your quality? We partner with many extruder and screw & barrel makers in Europe and Asia, all satisfied with our quality. Before shipping, we provide test reports for material, heat treatment, and tolerance. 6. Can I improve the current screw and barrel properties? For unsatisfactory output or melt quality, our engineers can revise or redesign your screw and barrel. Customized solutions are available. |
| production line | specification range | key feature |
| Conical twin screw & barrel |
Ø25/50–Ø185/340 mm |
Variable compression designs |
| Parallel twin screw & barrel |
Ø45/2 –Ø340/2 mm |
High-output configurations |
| Extruder single screw & barrel |
Ø20– Ø500mm (L/D: 15-55) |
Precision metering sections |
| Injection screw & barrel |
Ø20–Ø300mm (Clamping: 100-35,000 kN) |
Wear-resistant alloys |
| Rubber machine screw & barrel |
Ø20 – Ø650 mm |
Cold-feed/pin-type variants |
| Material | ||
|
38CrMoAl(1.8509) |
D2 |
AISI316 |
|
34CrAlNi7(1.8550) |
DC53 |
AISI420 |
|
31CrMoV9 (1.8519) |
Gr12MoV |
9Cr18MoV |
|
40CrNiMo |
440C |
17PH-4 |
|
42CrMo |
AISI304 |
Incoel 718 |
|
40Cr |
S600 |
Hasteloy C-276 |
|
C45 |
1.2316 |
Incoel 625 |
|
SKD11 |
1.4462 |
Monel 400 |
|
SKD11 |
1.4404 |
Monel 500 |
পণের ধরন : রাবার মেশিন স্ক্রু এবং ব্যারেল
